    B154SW01 VB 15.4 inch Mirror Haze Hard coating TFT LCD Screnn

    Ask Lasest Price
    Brand Name : AUO
    Model Number : B154SW01 VB
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 100000 Unit/Units per Month
    Delivery Time : 7 Days
    • Product Details
    • Company Profile

    B154SW01 VB 15.4 inch Mirror Haze Hard coating TFT LCD Screnn

    B154SW01 VB 15.4 inch Mirror Haze Hard coating TFT LCD Screnn


    B154SW01 VB LCD Panel Product details :


    AUO LCD SCREEN B154SW01 VB
    Panel BrandAUO
    Panel ModelB154SW01 VB
    Panel Size15.4"
    Panel Typea-Si TFT-LCD , LCM
    Resolution1680(RGB)×1050 [WSXGA+] 128PPI
    Pixel FormatRGB Vertical Stripe
    Display Area331.38(W)×207.11(H) mm
    Bezel Opening335.0(W)×210.7(H) mm
    Outline Size344(W)×222(H)×6.5(D) mm
    SurfaceMirror (Haze 0%), Hard coating (3H)
    Brightness200 (Typ.)
    Contrast Ratio400 : 1 (Typ.) [Transmission]
    Viewing Angle65/65/45/55 (Typ.) (CR≥10)
    Display ModeTN, Normally White, Transmissive
    Response Time8 (Typ.)(Tr+Td) ms
    Display Colors262K , 45% NTSC
    Lamp TypeCCFL [1 pcs] , 12K hours, no driver
    Frequency60Hz
    Touch ScreenWithout
    Signal InterfaceLVDS (2 ch, 6-bit) , terminal, 30 pins
    Input Voltage3.3V (Typ.)
    EnvironmentStorage temperature: -25 ~ 60 °C Operating temperature: 0 ~ 50 °C
    B154SW01 VB 15.4 inch Mirror Haze Hard coating TFT LCD Screnn
    B154SW01 VB LCD Module Reminder:

    Product Information:

    While product information is sourced from the internet, we assure you that our pictures are genuine representations of the product. We ship your order exactly as depicted in our images. To avoid any inconvenience, please compare our pictures with your desired product before making a purchase. Please note that return postal costs for an incorrect purchase are at the buyer's expense.


    Order Processing Time:

    Your order will be processed and shipped out within 2-7 working days from the date of purchase.


    Arrival Time:

    The estimated arrival time for your order is between 30-60 days, or even longer, depending on the postal service in your country. If you haven't received your product within 60 days, we kindly ask for your patience and suggest waiting a few more days.


    Shipping Method:

    If you have chosen the shipping option "China Post Ordinary Small Packet Plus," please be aware that this method does not provide tracking outside of China. We appreciate your understanding and patience in waiting for your package to arrive. Thank you for your cooperation.


    B154SW01 VB LCD Panel Shipping and Package :


    B154SW01 VB LCD Module Return Policy:

    Return Conditions:

    Returned products must be in their original condition, including the box, packaging, and all other accessories.
    Returns that result from customer error will be subject to an actual shipping fee deduction from the refund.


    Refund or Replacement:

    Upon receipt of the returned item, we will inspect it to ensure it meets our return conditions.


    Depending on the circumstances, we will offer a partial or full refund or a replacement at our cost.


    Contact Us:
    To initiate a return or if you have any questions regarding the return process, please contact us at [sales@yongs-hk.com]. Our dedicated customer service team will be happy to assist you.


    Please note that shipping fees and YONGS (Your Own Negligence Goods Shipping) charges are non-refundable.


    B154SW01 VB LCD Panel FAQ :

    Q: How long will I receive my goods of B154SW01 VB?

    A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.


    Q: How to make payment for B154SW01 VB?

    A: We accept T/T , Paypal , western union .


    Q: What happen if the B154SW01 VB receive can't work ?

    A: The HSD123JPW3-A11 will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.


    Q: Can You declare my order of B154SW01 VB at a very low value ?

    A: Yes , we can . pls inform us before shipping .


    B154SW01 VB LCD Module Contact Us:


    We are dedicated to providing exceptional customer service. If you have any questions or concerns regarding the B154SW01 VB LCD Module, please do not hesitate to reach out to us. Our team is committed to promptly addressing all inquiries and providing the assistance you need.


    You can email us at [sales@yongs-hk.com]. We strive to respond to all messages within 24 hours. However, please understand that there may be a delay in response during non-business hours.


    Your satisfaction is our priority, and we look forward to assisting you with any issues or queries you may have. Thank you for choosing our products.
