AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI

Shenzhen Yongsheng Innovation Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI from wholesalers

    Buy cheap AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI from wholesalers
    • Buy cheap AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI from wholesalers
    • Buy cheap AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI from wholesalers
    • Buy cheap AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI from wholesalers

    AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI

    Ask Lasest Price
    Brand Name : AUO
    Model Number : B156XTN08.1
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 100000 Unit/Units per Month
    Delivery Time : 7 Days
    • Product Details
    • Company Profile

    AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI

    AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI


    B156XTN08.1 Product details :


    AUO LCD SCREEN B156XTN08.1
    Panel BrandAUO
    Panel ModelB156XTN08.1
    Panel Size15.6"
    Panel Typea-Si TFT-LCD , LCM
    Resolution1366(RGB)×768 WXGA 100PPI
    Pixel FormatRGB vertical bars
    Display Area344.232 × 193.536 mm (H×V)
    Outline Size350.66 × 216.15 × 3.2 mm (H×V×D)
    TreatmentAntiglare
    Brightness220 cd/m² (Typ.)
    Contrast Ratio400:1 (Typ.) (TM)
    View Direction6 o'clock
    Viewing Angle45/45/15/35 (Typ.) (CR≥10)
    Display ModeTN, Normally White, Transmissive
    Response Time8(Typ.)(Tr/Td) ms
    Display Colors262K , 45% NTSC
    Lamp TypeWLED , 15K hours, with LED driver
    Designed ForLaptop
    Frequency60Hz
    Touch ScreenWithout
    Signal InterfaceeDP (2 Lanes) , eDP1.2 , 30 pins Connector
    Input Voltage3.3V (Typ.)
    EnvironmentStorage temperature: -20 ~ 60 °C Operating temperature: 0 ~ 50 °C
    AUO Vertical Stripe 15.6 Inch LCD Pane B156XTN08.1 1366*768 100PPI

    Hello, dear customers. Welcome to our shop.


    We sell all brands of laptop screens, such as the screen for Lenovo HP Asus Acer Dell, and so on. If you need any other laptop screens, please feel free to contact us.


    B156XTN08.1 Attention before buying:


    To avoid mistakes, please send us your screen backside photo or laptop model label photo after placing an order. We will ship your goods as soon as possible after confirming the screen is suitable for your laptop.


    B156XTN08.1 Our features :


    1. Original quality guarantee.


    2. Superior After-Sale service;


    3. The most competitive prices here can provide;


    4. Small order quantity accepted.


    5. Offer 12 months of warranty;


    6. Experienced staff can help you to solve your problem anytime.


    B156XTN08.1 Payment Items:


    Wire Transfer /MoneyGram /Western Union / PayPal /WeChat Pay / AliPay / Credit Card


    B156XTN08.1 Packaging:


    Normal packagingExport carton


    custom packing


    B156XTN08.1 Shipment Details:


    1: Please carefully confirm your address after placing an order. We will send the product to you 24 hours after receiving the payment.


    2: Items shipped from China by airmail: Arrive in most countries within 15-30 business days


    B156XTN08.1 FAQ:


    Q: Can I pay my order of B156XTN08.1 via credit card ?

    A: Yes!you can use your credit card through your Paypal account.


    Q: How long is the warranty ?

    A: We offer 90days warranty .


    Q: Can You declare my order of B156XTN08.1 to a lower price in commercial invoice for customs ?

    A: Yes , we can . pls inform us before shipping .


    Q: How to make payment of B156XTN08.1 ?

    A: We accept T/T , Paypal , western union .


    B156XTN08.1 Shipping and Package :
